₱529.00
Specification Basic Information Input Interface USB-Type-C Male Output Interface USB-Type-C Male Transmission Rate Up to 10Gbps Control Chip E-Marker Chip: HUSB332D Others Number of Cores: 6 cores + 6 layersCurrent Capacity: 5A (Max)Connector Type: USB-C to USB-CUSB-C Pins: 12-pinConnector Details:Terminal: Gold-plated 3U"Core: Black rubber (94V-0)Enclosure: Stainless steel, nickel-platedDurability:Plug and...
Specification
| Basic Information | ||
| Input Interface | USB-Type-C Male | |
| Output Interface | USB-Type-C Male | |
| Transmission Rate | Up to 10Gbps | |
| Control Chip | E-Marker Chip: HUSB332D | |
| Others | Number of Cores: 6 cores + 6 layers Current Capacity: 5A (Max) Connector Type: USB-C to USB-C USB-C Pins: 12-pin Connector Details: Terminal: Gold-plated 3U" Core: Black rubber (94V-0) Enclosure: Stainless steel, nickel-plated Durability: Plug and play cycles: 10,000 times Swing cycles: 3000 times (300g, 90° angle, 30/min) Resistance: Data cable: ~0.33Ω/m Power cable: 2m: ~0.07Ω/m Interface Version: USB 2.0 Data Transfer Rate: 480 Mbps Charging Protocols: PD / PPS Flame Retardant Grade: GB/T 5169.23-2008 Operating Temperature: 0°C to 45°C Storage Temperature: -15°C to 70°C Environmental Compliance: EU RoHS 2.0 REACH SVHC California Prop 65 TSCA China RoHS |
|
| Physical Specification | ||
| Material | Core Material: Tin-Coated Copper Outer Coating: TPE Shielding: Aluminum foil + woven mesh |
|
| Color | Black | |
| Cable Length | 2 Meter | |
